Electronics

The SPARK Flex is a new smart motor controller that is compatible with the REV ION System. Its dockable form factor allows for the direct mounting onto a NEO Vortex, simplifying wiring while maintaining flexibility. Improving upon the...

The REV Power Distribution Hub (PDH) is the latest evolution in power distribution for the FIRST Robotics Competition (FRC).  With 20 high-current (40A max) channels, 3 low-current (15A max), and 1 switchable low-current channel, the PDH...

The REV USB PS4 Compatible Gamepad is compatible with both the REV DUO and REV ION Systems. Plug the REV Gamepad directly into a Driver Hub to enable feature rich control of your robot. Additionally, when plugged into a PC, it offers an Xbox...

The REV Pneumatic Hub is a standalone module that is capable of switching both 12V and 24V pneumatic solenoid valves. The Pneumatic Hub features 16 solenoid channels which allow for up to 16 single-acting solenoids, 8 double-acting solenoids, or a...

The CAN Terminator Pack provides two compact, plug-ready termination options for teams looking to maintain reliable CAN bus performance anywhere in their robot’s wiring. Each terminator uses a small 10mm x 10mm internal circuit board sealed with...

The MAXSpline Grommet provides a simple way to route wires through MAXTube while preventing abrasion against bare aluminum. Made from pliable 60A rubber, it press-fits into the MAXSpline Bore on MAXTube with a 1/8 inch wall, creating a clean pass-through...

The REV Through Bore Encoder V2 provides precise, reliable shaft position measurement with both incremental (ABI quadrature) and absolute (pulse-width) outputs. Its ½" hex through bore mounts easily within common FRC/FTC mechanisms, and the...

The SPARK MAX Data Port Breakout Board makes it easy to connect external sensors to the SPARK MAX Data Port. For additional information on the SPARK MAX Data Port, please take a look at the SPARK MAX User's Manual. Analog Input Issue - Affects Rev. A...

REV Robotics custom ATO sized auto-resetting breakers are designed to give reliable protection for FRC robot actuators.  These custom developed breakers adhere to SAE Standard J553 and will give consistent performance even after hundreds of breaker...

The REV Servo Hub is compatible with both the REV ION and REV DUO systems. Over a single communication interface it can provide advanced control of up to six (6) servos. This means that the Servo Hub needs no additional PWM cabling between it and your...

The SPARK Flex Data Port Pigtail Cable breaks out the SPARK Flex Data Port to individual unterminated wires and is useful for connecting custom circuits or sensors without a standard connector. It features the keyed and locking Data Port connector to...

The SPARK Flex Data Port Breakout Cable breaks out the default pin functions of the SPARK Flex Data Port into commonly used connectors for external sensors. The keyed and locking Data Port connector ensures a secure and aligned fit when plugged into the...

Mounting your SPARK MAX Motor Controller (REV-11-2158) has never been easier with the help of the SPARK MAX Mounting Bracket. Configured with a hole pattern compatible with a 1/2in grid and allowing the mode and status light to be seen, this...

The REV Robotics 2m Distance Sensor uses the ST Microelectronics VL53L0X Time-of-Flight (ToF) laser-ranging module to measure distances up to 2 meters with millimeter resolution. Unlike other ranging sensors that rely on the intensity of reflected light,...

The REV Robotics Magnetic Limit Switch is a three-sided active-low digital hall effect switch with three internal hall effect elements located on the top and sides of the sensor. The three elements are connected in parallel so that any one of them will...

These JST PH 6-pin Extension Cables are intended to extend the reach of sensor cables without having to cut and splice wires. Specifications REV-11-1275-PK4: Length: 36in REV-11-3327: Length: 30cm

Connect the REV Through Bore Encoder directly to the SPARK MAX Data Port using this adapter. This adapter connects the Absolute Duty Cycle output of the Through Bore Encoder to the correct SPARK MAX Data Port pins, leaving the incremental quadrature...

The REV Robotics Analog Pressure Sensor is a 5V sensor that can measure pressures up to 200 PSI. It outputs an analog voltage that is proportional to the measured pressure and can plug directly into the roboRIO or the More Board V2.0...

The REV Mini Power Module (MPM) is a compact power distribution module that allows you to securely and quickly power peripheral devices to your robot. Need more low-current channels on your PDH? Wire the MPM to one of the high-current channels on the PDH...

Building on the robust foundation of the original SPARK, the SPARK MAX Motor Controller incorporates advanced brushed and brushless DC motor control in a small and easy-to-use package with PWM, CAN, and USB connectivity. Never before has an FRC...
